Wood chipper mounted on road trailer: VEGETOR 160M

The thermal engine mounted wood chipper allows you to drive on the road. Ideal for landscapists, renters, private people... this 5 in 1 wood chipper is an excellent choice: it ensures you to produce any kind of chips!

VEGETOR 160 M (maximum wood diameter 160 mm).

Rotor «5 in 1»:
- 3 standards modes: 2 knives or 2 rows of hammers or knives + hammers.
- 2 optional modes: 1 knife or 4 rows hammers

Freedom to drive on the road at 130Km/h. Trailer with drawbar, swivelling wheel, towing ring Ø 50mm, rear support, lighting line.

Motorization: Thermal engine petrol or Diesel 22hp to 38hp with Turbo according to the model.

Centrifugal clutch driven by 3 belts.

NOSTRESS regulation with 3 positions: ECO / MEDIUM / MAX.

Hopper can be easily foldaway for a compact machine in transport position.

Swivelling blower 360° with adjustable cap (with chain).

Adjustable feeding roller speed to increase or to reduce the size of the shavings.

Extra-wide feeding hopper (XL) with safety bar mounted on top for avoiding any untimely release caused by wood

Model	VEGETOR 160 M
Maximum wood diameter	160 mm
Opening (W x H)	210 x 165 mm
Hopper dimension ;(L x W x H)	1,72 x 1,03 x 0,73 m
Foldaway hopper	Yes
Feeding roller with independent drive	1, chevron shaped, 60 cm width
Hydraulic adjustment or roller speed	Yes with a knob
Type of rotor	Rotor 5in1
Rotor "5 in 1" specifications (standard)	2 knives + 2 rows of 8 hammers
NOSTRESS device	Yes with 3 presettings
Blower	Swivelling on 360° with handle and adjustable cap (with chain)
Motorization	Honda petrol 22.1 hp - 2 cylinder - air cooling Kohler petrol 34 or 38 hp - 2 cylinder - air cooling Lombardini Diesel 25.2 hp - 3 cylinder - water cooling Lombardini Diesel 35 hp - 4 cylinder - water cooling
Transport dimensions (L x W x H)	Without conveyor, unbraked axle : 3,95 x 1,45 x 1,87m with conveyor, unbraked axle : 3,79 x 1,45 x 1,87 m Braked axle : 4,21 x 1,45 x 1,87 m
Working dimensions (L x W x H)	Without conveyor, unbraked axle : 4,32 x 1,45 x 2,43 m with conveyor, unbraked axle : 4,16 x 1,45 x 2,43 m Braked axle : 4,58 x 1,45 x 2,43 m
Weight	From 635 to 800 Kg
Number of axle	1 adjustable with towing
Road trailer	With swiveling wheel, rear support stand, towing knob Ø 50mm / ring 42/68 in option
Maximum transport speed	130 km/h
Hourly production (estimated)	From 3000 to 4000 kg (from 9 to 12 MAP)
