Tilting mast post driver: VITI
Compact 95 cm post driver: ideal to be adapted on a winegrowing tractor. The posts are driven with a 160 Kg sliding sledgehammer mounted on the vertical mast. This machine enables a work on flat or irregular vineyards.
![](https://gesproequipement.com/wp-content/uploads/2021/01/enfonce_piquet_vigne_mat_viti-2.png)
The 95 cm width eases the crossing between the rows.
Possibility to drive posts up to 3000 mm.
Standard +/- 15 ° hydraulic inclination to drive posts in a perpendicular way and/or tilted posts (support legs).
Serial hydraulic offset (425 mm).
160 Kg striated and concave mass for a flat striking on the top of the stake; the halyard can be adjusted.
Hydraulic post-clamp with guiding rollers for an excellent hold of the post during the driving process.
Secured lowering of the hammer thanks to the connection between the post-clamp and the hammer.
Drive through tractor pump with 2 male quick couplers or 540 rpm PTO (10 L/min. oil flow).
2 storage stands for a better steadiness during the work and the parking.
Model |
Tilting mast post driver: VITI |
Maximal post length |
3000 mm |
Mass weight |
160 Kg |
Striking power |
1618 joule/m |
Hydraulic offset (serial) |
1090 mm from the tractor axle |
Hydraulic inclination (serial) |
+/- 15° |
Dimensions (L x W x H) |
1410 x 950 x 3070 mm |
Weight |
- |
Drive |
Tractor pump with 2 couplers or 540 rpm PTO, 10 L/min. |
Linkage |
3 point N°2 with removable locking pins |
Hydraulic valve |
4-way |
The 95 cm width eases the crossing between the rows.
Possibility to drive posts up to 3000 mm.
Standard +/- 15 ° hydraulic inclination to drive posts in a perpendicular way and/or tilted posts (support legs).
Serial hydraulic offset (425 mm).
160 Kg striated and concave mass for a flat striking on the top of the stake; the halyard can be adjusted.
Hydraulic post-clamp with guiding rollers for an excellent hold of the post during the driving process.
Secured lowering of the hammer thanks to the connection between the post-clamp and the hammer.
Drive through tractor pump with 2 male quick couplers or 540 rpm PTO (10 L/min. oil flow).
2 storage stands for a better steadiness during the work and the parking.
