Automatic rod driver: TUNNELMATIC
The RABAUD Tunnelmatic allows an automatic and regular rod driving as well as the tunnel's creation in one single pass. No tiredness due to manual driving.
Automatic and regular rod driving as well as creating the tunnel in one single pass
Guiding of the rods, formation according to the size; laying with pneumatic cylinders
Compressor driven through PTO (8 HP needed).
Programmable automaton: you can choose the distance between each rod (from 14 cm)
Forwarding speed of the tractor until 2 km/h depending on chosen distance
Regularity for the rod depth, distance and tunnel formation
Perfect tightening of plastic films
Easy and safe operating thanks to the programmable automaton
Model |
TUNNELMATIC |
Linkage |
3 points n°2 (automatic) |
Minimum tractor power |
60 HP - 44 Kw |
Tunnel width |
from 900 to 1600 mm depending on model |
Max. rod length |
2,30 m |
Rod diameter |
from 4,40 to 6 mm |
Distance between each rod |
from 14 cm |
Dimensions (L x W x H) |
1,73 x 2,50 x 1,83 m |
Weight (without plastic film system) |
780 Kg |
Automatic and regular rod driving as well as creating the tunnel in one single pass
Guiding of the rods, formation according to the size; laying with pneumatic cylinders
Compressor driven through PTO (8 HP needed).
Programmable automaton: you can choose the distance between each rod (from 14 cm)
Forwarding speed of the tractor until 2 km/h depending on chosen distance
Regularity for the rod depth, distance and tunnel formation
Perfect tightening of plastic films
Easy and safe operating thanks to the programmable automaton
